Process a Test Request and Respond to a Trade Cancellation Request

The purpose of this test is to verify that the client system can successfully connect and maintain an STP FIX session while processing Trade Capture Reports for Trade Cancellation Events on CME ClearPort / CME GlobexTrades.

See:CME STP - Post-Trade Events



1. Select a SenderComp / API ID from the drop-down and select ASSIGN if not already assigned.
2. (If applicable) From the Instrument(s) drop-down, select the desired instrument if the instrument is not already locked.
3. Select the START TEST button.

Note: DO NOT select the START TEST button once the test is in progress.

Note: If a test is not proceeding to the next step, clicking the Refresh button () below the test steps may resolve the issue.



1. To run a Detect a Gap test:

1. Submit a Logon (35=A).
2. Receive a Logon Acknowledgment (35=A).
3. Submit a Trade Capture Report Request (35=AD and 263=1).
4. Receive a Trade Capture Report Response (35=AQ).
5. Receive a Trade Capture Report(s) (35=AE|487=2) of the Original Trade.
6. Receive Trade Capture Report(s) (35=AE|487=1) with the Cancel (Offset) Trade Message.
7. Submit a Logout (35=5) Request.
8. Receive a Logout Acknowledgment (35=5).
